Pitch(间距) | 5.08mm | ||
Approval(认证) | ![]() |
||
Rated voltage(电压) | 300V | 320V | |
rated current(电流) | 15A | 20A | |
wire range(线径) | |||
PCB hole Dia(PCB直径) | Φ1.6mm | ||
Screw (螺丝) | |||
Housing Material(本质材料) |
Poles(级数) | Model(型号) |
02 | TLCH-300R-02P |
.. | .. |
24 | TLCH-300R-24P |
PS:仅供参考,以公司规定的具体数据为准
