Pitch(间距) | 5.00mm | ||
Approval(认证) | ![]() |
||
Rated voltage(电压) | 300V | ||
rated current(电流) | 16A | ||
wire range(线径) | |||
PCB hole Dia(PCB直径) | Φ1.6-1.7mm | ||
Screw (螺丝) | |||
Housing Material(本质材料) |
Poles(级数) | Model(型号) |
04 | TLPHD-203R-04P |
.. | .. |
48 | TLPHD-203R-48P |
PS:仅供参考,以公司规定的具体数据为准
