Pitch(间距) | 5.00mm | ||
Approval(认证) | ![]() |
||
Rated voltage(电压) | 300V | ||
rated current(电流) | 20A | ||
wire range(线径) | 24-12AWG | ||
PCB hole Dia(PCB直径) | Φ1.5-1.7mm | ||
Screw (螺丝) | M2.5 | ||
Housing Material(本质材料) |
Poles(级数) | Model(型号) |
02 | TL214V-02P |
.. | .. |
24 | TL214V-24P |
PS: 仅供参考,以公司规定的具体数据为准!
