Pitch(间距) | 3.50mm | ||
Approval(认证) | ![]() |
||
Rated voltage(电压) | 300V | ||
rated current(电流) | 8A | ||
wire range(线径) | 28-16AWG | ||
PCB hole Dia(PCB直径) | |||
Screw (螺丝) | M2.5 | ||
Housing Material(本质材料) |
Poles(级数) | Model(型号) |
04 | TLPSDW-007-04P |
.. | .. |
48 | TLPSDW-007-48P |
PS:仅供参考,以公司规定的具体数据为准
