Pitch(间距) | 10.00mm | ||
Approval(认证) | ![]() |
![]() |
|
Rated voltage(电压) | 600V | 1000V | |
rated current(电流) | 66A | 76A | |
wire range(线径) | 20-4AWG | 0.75-16mm² | |
PCB hole Dia(PCB直径) | Φ1.7mm | ||
Screw (螺丝) | |||
Housing Material(本质材料) |
Poles(级数) | Model(型号) |
02 | TLM-704VA-02P |
.. | .. |
12 | TLM-704VA-12P |
PS: 仅供参考,以公司规定的具体数据为准!
