Pitch(间距) | 6.35mm | ||
Approval(认证) | ![]() |
||
Rated voltage(电压) | 300V | ||
rated current(电流) | 13.5A | ||
wire range(线径) | 22-16AWG | ||
PCB hole Dia(PCB直径) | Φ1.6mm | ||
Screw (螺丝) | M2.6 | ||
Housing Material(本质材料) |
Poles(级数) | Model(型号) |
02 | T101-W11-02P-XC |
.. | .. |
30 | T101-W11-30P-XC |
PS: 仅供参考,以公司规定的具体数据为准
