Pitch(间距) | 9.50mm | ||
Approval(认证) | ![]() |
![]() |
|
Rated voltage(电压) | 300V | 450V | |
rated current(电流) | 25A | ||
wire range(线径) | 22-10AWG | 2.5mm² | |
PCB hole Dia(PCB直径) | Φ2.2mm | ||
Screw (螺丝) | M3.5 | ||
Housing Material(本质材料) |
Poles(级数) | Model(型号) |
02 | B950C-02-02P |
.. | .. |
24 | B950C-02-24P |
PS: 仅供参考,以公司规定的具体数据为准!
