間隔(Pitch) | 15.24mm | ||
認証(Approval) | ![]() |
![]() |
|
電圧(Rated voltage) | 600V | 1000V | |
電流(rated current) | 60A | 76A | |
ワイヤー(wire range) | 20-6AWG | 0.5-16mm² | |
PCB 直径(PCB hole Dia) | Φ1.5mm | ||
スクリュー (Screw) | M4 | ||
材料の性質(Housing Material) |
シリーズ(Poles) | モデル(Model) |
02 | TL804S2-02P |
.. | .. |
16 | TL804S2-16P |
PS: For reference only,Prevail Specific data by Specification company provided
