간격(Pitch) | 5.00mm | ||
인증(Approval) | ![]() |
![]() |
|
전압(Rated voltage) | 250V | 450V | |
전류(rated current) | 15A | ||
철사(wire range) | 22-12AWG | 2.50mm² | |
PCB 직경(PCB hole Dia) | Φ1.4-1.6mm | ||
나사 (Screw) | M2.5 | ||
물질의 성질(Housing Material) |
시리즈(Poles) | 모델(Model) |
02 | TL209V-02P |
.. | .. |
24 | TL209V-24P |
PS: For reference only,Prevail Specific data by Specification company provided
